Flash Magnetic Switch (Lubed)
$4.99 – $27.99
Ultra-light Hall Effect (HE) Switches.
Light 25gf initial force;
Thocky sound profile with a linear feel close to mechanical switches;
High-precision premium gaming experiences without breaking the bank.
Flash Magnetic Switch
LED Diffuser丨Lubed丨Adjustable Actuation
Specification
- Total Travel: 3.5±0.1mm
- Initial Force: 25gf
- End Force: 48gf
- Initial Magnetic Flux: 90+15GS (PCB1.6mm)/110+15GS (PCB1.2mm)
- Bottom Magnetic Flux: 580+50GS (PCB1.6mm)/720+50GS (PCB1.2mm)
- Top/Stem/Bottom: PC/POM/PA66
Adjustable Actuation for Precision and Customization
The Flash Hall Effect Switches are magnetic switches that operate on Hall Effect or TMR sensing technology, using magnetic fields to detect key actuation.
Unlike traditional mechanical switches that rely on metal contacts, magnetic switches track key position in real time via sensors.
Flash Switches, which can be used in the FUN60 and M1 V5 TMR versions, offer features such as 0.01mm precision and custom actuation for enhanced customization and control through MonsGeek Driver.
*Please check switch compatibility with the keyboard before use.
Compatibility
Flash switches are compatible with MonsGeek FUN60 Pro & Max HE, FUN60 Ultra HE, FUN60 Ultra TMR, and M1 V5 TMR Magnetic Switch Keyboards, achieving 0.01mm precision.
They should also theoretically be compatible with other downward-facing N-pole magnetic switches keyboards. More tests will be rolled out.
Note: They are NOT compatible with MX mechanical switch PCBs as well as S-pole magnetic switches PCBs. They’re not compatible with MOD007B HE / MOD007B YOTD v1, which use a downward-facing S-pole.
LED Diffuser
The diffuser optimizes light dispersion for sharper, more defined keycap legends. Switches with LED condenser are perfect for gamers and typists who want both superior typing performance and stunning aesthetics.
